ENAC Accredited Photometric Tests
LED luminaires: UNE-EN 13032-4.; CIE 34; CIE 52. Luminaires with sources other than LEDs: UNE-EN 13032-1; CIE 34
Luminous intensity distribution (tables including values at different C planes and gamma angles, with the uncertainty, polar and Cartesian graphical representations).
Luminous flux, zonal fluxes, fractions of the flux emitted towards the upper and lower hemisphere, ICD codes.
Efficiency, efficacy.
Isoilluminance curves
Beam opening, illuminance cone (minimum, average and maximum illuminance at different heights). .
Throw, spread and control values for road luminaires. Isocandela diagram and roadway / walkway utilization factor curves.
Power supply and electric parameters of the product (power, current, voltage, power factor).
ENAC Accredited Colorimetric Tests
LED luminaires: UNE-EN 13032-4.; CIE 250; CIE 15; CIE 13.3. Luminaires with sources other than LEDs: UNE-EN 13032-1; CIE 63; CIE 15; CIE 13.3.
Normalized spectral distribution.
Color coordinates (x, y).
Color coordinates (u', v').
Correlated color temperature and desviation from the black body (Duv).
Color rendering index ( Ra).
Angular variation and angular uniformity of color.
ENAC Accredited, Photobiological safety
Photobiological safety testing of luminaires, lamps, and other lighting devices according to UNE-EN 62471.
Risk assessment according to IEC 62471-7 and IEC TR 62778 (although the standard has been repealed, it is still referenced in some luminaire safety standards).
Blue light risk group classification (LB, EB).
Determination of product compliance based on its application group.
Determination of illuminance, Ethr, and distance, dthr, where the transition from RG2 to RG1 occurs. Although the standard that regulates it has been repealed, it is a parameter of interest, referenced in other standards.
European Product Registry for Energy Labelling
As of 1 January 2019, suppliers (manufacturers, importers or authorised representatives established in the EU) must register their products in the European Product Registry for Energy Labelling (EPREL).
In May 2022, the database was launched for public access and consultation.
